Specifications
Dimensions & Weights
Width: 34 3/10 Inch
Depth: 12 3/5 Inch
Height: 31 4/5 Inch
Capacity
Heating Capacity: 36,000 BTU
General
AC System Type: Mini Split
Component Type: Outdoor Unit
No. of Rooms: 4
Electrical Data
Running Current Cooling - Max. (Amps): 14.2 Amps
Running Current Heating - Max (Amps): 16.3 Amps
Power Input Cooling - Max. (Watts): 3,210 Watts
Power Input Heating - Max. (Watts): 3,700 Watts
Performance
Energy Star Certified: No
Refrigeration System
Max. Line Length - Each: 82 Ft.
Technical Details
ADA Compliant: No
Features
***Capacity varies depending on the combination.***
***See Engineering and Specifications Guide for combinations of indoor units.***
Standard Features
Defrost/Deicing
Restart Delay (3-Minutes)
Self Diagnosis
Soft Start
Auto Operation (Artificial Intelligence)
Auto Restart Operation
Low Ambient Operation
Gold Fin Anti-Corrosion
Exterior Units Includes
Exterior Unit
Sufficient Refrigerant For Charging 2, 3 or 4 Indoor Coils
Installation Manual
