Specifications

Dimensions & Weights Width: 35 1/4 Inch Depth: 8 9/32 Inch Height: 11 7/32 Inch Net Weight: 23 Lbs. Shipping Weight: 27 Lbs. Capacity BTU Class: 9,000 BTU Heating Capacity: 10,400 BTU General AC System Type: Mini Split Component Type: Indoor Unit Operation: Cooling with Heat Pump Placement Type: Wall Mount Wireless Remote Control(s) Included: Included Wired Remote Control(s) Included: Optional Electrical Data Power Source V / Hz / Ø: (208/230/60/1) Rated Amps: 0.2 Amps Performance Fan: Cross-Flow No. of Fans: 1 Motor: Brushless Digitally Controlled Motor Drive: Direct Airflow Rate Low (CFM): 212 CFM Airflow Rate Medium (CFM): 230 CFM Airflow Rate High (CFM): 247 CFM Operating Sound Level - Low (dB): 27 dB Operating Sound Level - Medium (dB): 30 dB Operating Sound Level - High (dB): 33 dB Temperature Sensor: Thermistor Entering Mixed Air - Cooling: 57° - 77°F DB Entering Mixed Air - Heating: 59° - 81°F DB Piping Connections Power and Communication Cable - No.: 4 Power and Communication Cable - AWG: 18 Liquid Line Outer Diameter: 1/4 Inch Suction Line Outer Diameter: 3/8 Inch Drain Line Outer Diameter: 13/16 Inch Drain Line Inner Diameter: 5/8 Inch Refrigeration System Refrigerant Type: R-410A Refrigerant Connection Type: Flare Refrigerant Control: EEV Features Human Detection Technology: No Room-Freeze Protection: No Filter Clean Notification: No Hot Start Heating System (Heat Pumps Only): No Program Timer: Yes Manual Power Switch: Yes Defrost/Deicing: No Air Filter: Yes Filters Washable?: Yes Filters Anti-microbial?: Yes Restart Delay: No Self-diagnosis: No Condensate Sensor Connection: No Soft Start: No Quiet/Sleep Mode: No Self-Cleaning Indoor Coil: Yes Built-in Drain Pump (Indoor Unit): Yes Hidden Display: No Surge Cool/Heat: Yes Auto Operation: Yes Auto Restart on Power Failure: Yes Auto-changeover: No Automatic Louver Adjustment: No 4-Way Swing: No Dehumidifying Mode: No No. of Fan Speeds: 5 Technical Details ADA Compliant: No Warranty Terms Parts Warranty: 5 Year GTIN UPC: 048231376976
