Specifications

Dimensions & Weights Width: 35 1/4 Inch Depth: 8 9/32 Inch Height: 11 7/32 Inch Net Weight: 23 Lbs. Shipping Weight: 27 Lbs. Capacity BTU Class: 12,000 BTU Heating Capacity: 13,800 BTU General AC System Type: Mini Split Component Type: Indoor Unit Operation: Cooling with Heat Pump Min No. of Connectible Indoor Units: 1 Max No. of Connectible Indoor Units: 1 Placement Type: Wall Mount Wireless Remote Control(s) Included: Included Wired Remote Control(s) Included: Optional Electrical Data Power Source V / Hz / Ø: (208/230/60/1) Running Current Cooling - Rated (Amps): 7.4 Amps Running Current Heating - Rated (Amps): 7.4 Amps Minimum Ampacity (Amps): 10 Amps Max. TD Fuse/Breaker: 15 Amps Power Input Cooling - Rated (Watts): 960 Watts Power Input Heating - Rated (Watts): 1,040 Watts Rated Amps: 0.15 Amps Performance Fan: Cross-Flow No. of Fans: 1 Motor: Brushless Digitally Controlled Motor Drive: Direct Compressor Noise Level - Cooling (dB): 45 dB Compressor Noise Level - Heating (dB): 48 dB Energy Star Certified: Yes Airflow Rate Low (CFM): 300 CFM Airflow Rate Medium (CFM): 318 CFM Airflow Rate High (CFM): 335 CFM Operating Sound Level - Low (dB): 31 dB Operating Sound Level - Medium (dB): 36 dB Operating Sound Level - High (dB): 39 dB Temperature Sensor: Thermistor Piping Connections Power and Communication Cable - No.: 4 Power and Communication Cable - AWG: 18 Liquid Line Outer Diameter: 1/4 Inch Suction Line Outer Diameter: 3/8 Inch Drain Line Outer Diameter: 27/32 Inch Drain Line Inner Diameter: 5/8 Inch Power Supply Cable - No. x AWG: 3 x 14 Refrigeration System Refrigerant Type: R-410A Compressor Type: Twin Rotary Refrigerant Connection Type: Flare Refrigerant Control: EEV Refrigerant Charge: 2.21 Ft. Piping Length (No Additional Refrigerant): 41 Ft. Min. Line Length - Each: 9.8 Ft. Max. Line Length - Each: 82 Ft. Min. Line Length - Total: 9.8 Ft. Max. Line Length - Total: 82 Ft. Max. Height Diff. btwn. Indoor and Outdoor Units: 49.2 Ft. Outside Temperature Range for Cooling - Min.: 14 °F Outside Temperature Range for Cooling - Max.: 118 °F Outside Temperature Range for Heating - Min.: -4 °F Outside Temperature Range for Heating - Max.: 65 °F Features Human Detection Technology: No Room-Freeze Protection: No Filter Clean Notification: No Hot Start Heating System (Heat Pumps Only): No Program Timer: Yes Manual Power Switch: Yes Defrost/Deicing: No Air Filter: Yes Filters Washable?: Yes Filters Anti-microbial?: Yes Restart Delay: No Self-diagnosis: No Condensate Sensor Connection: No Soft Start: No Inverter (Variable speed compressor): Yes Quiet/Sleep Mode: No Self-Cleaning Indoor Coil: Yes Built-in Drain Pump (Indoor Unit): No Hidden Display: No Surge Cool/Heat: Yes Auto Operation: Yes Auto Restart on Power Failure: Yes Auto-changeover: No Automatic Louver Adjustment: No 4-Way Swing: No Dehumidifying Mode: No Low Ambient Operating Threshold (F°): 14 Corrosion Protection: Yes No. of Fan Speeds: 5 WiFi Connected: Yes Technical Details ADA Compliant: No Voltage: 230/208 Volts Warranty Terms Parts Warranty: 5 Year GTIN UPC: 048231385749
